CORE ELECTRICAL SPECIFICATIONS

• ​Nominal Voltage: 51.2V.
• ​Nominal Capacity: 280Ah (@ 0.5C discharge current, 25±2°C).
• ​Nominal Energy (Power): 14.3 kWh.
• ​Charge Voltage: 56.4V.
• ​Discharge Cut-off Voltage: 44V.
• ​Continuous Charge/Discharge Current: 140A (Recommended @ 25±2°C).

​OPERATING RANGES & ENVIRONMENT

• ​Working Temperature (Charge): 0~50°C.
• ​Working Temperature (Discharge): -10~50°C.
• ​Storage Temperature: -20~55°C.
• ​SOC Range: 5%–100%.
• ​Recommended SOC Range: 10%–90%.
• ​Humidity: 10%–85%.
• ​Protection Level (IP Level): IP20.

​PHYSICAL & COMMUNICATION FEATURES

• ​Dimensions: 750 * 440 * 251 mm.
• ​Weight: 112 kg ± 5 kg.
• ​Communication Interface: CAN (Default) or RS485.
• ​Key Features: Includes a longer lifespan, improved safety, fast charging, high energy dsity, and a low self-discharger
